Surly Disc Trucker Frameset – 26″ Steel Hi-Viz Black

Surly Disc Trucker Frameset – 26″ Steel Hi-Viz Black

Original price was: $419.40.Current price is: $236.19.

21 in stock

SKU: FM1764 Category:

Surly Disc Trucker Frameset – 26″ Steel Hi-Viz Black GEOMETRY

Frame measurements (mm) 42cm 46cm 50cm 52cm 54cm 56cm
A. BB Drop 50 50 50 50 50 50
B. Chainstay Length 450 450 450 450 450 450
C. Fork Length – Axle to Crown 376 376 376 376 376 376
D. Fork Offset 45 45 45 45 45 45
E. Head Tube Angle (deg) 70 70 71 71 71 71
F. Headtube Length 125 130 170 185 205 225
G. Reach 362 371 369 374.5 378 387.5
H. Seat Tube Angle (deg) 75.0 74.5 74.0 73.5 73.0 73.0
I. Seat Tube Length – Center to Top 420 460 500 520 540 560
J. Stack 515 520 561 575.5 594.5 613
K. Standover 710 731 766 782 800 819.5
L. Top Tube Length (Effective) 500 515 530 545 560 575
M. Wheelbase 1026 1037 1040 1050 1060.5 1076
