Road or Gravel? 5 miles or 5 hours? Climb or Descend? Suffer or Smile? More power or less weight? Creo 2 isn’t about having to choose. It’s about having it all. With more power, big range, light weight, huge tire clearance, and Future Shock 2.0, it’s category-defying, making previously impossible rides possible.
– ALLOY UP FOR ANYTHING: Turbo Creo 2 is a category-defying bike. Alloy is a category-defying material. Now, every feature that makes Turbo Creo 2 a no-compromise road and gravel e-bike is available in our premium E5 Alloy. All roads, all conditions, all electric. Light, compliant, and tougher than anything you could throw at it.
– SUPERNATURAL AMPLIFICATION: The all-new TURBO SL 1.2 system delivers industry-leading efficiency for a range of up to 5 hours. It creates 33% more power (320 Watts) than its predecessor and delivers that power across an ideal pedaling cadence for a supernatural feel. With 43% more torque (50Nm), the power comes on instantly—making quick work of the steepest hills. But less is more when it comes to noise, so we reduced dBs by 40%. It’s literally whisper quiet.
– RE-TIRED FOR CONFIDENCE: 700c x 40 Tires Spec’d with a maximum tire size of 700c x 47. The big tire volume delivers a smooth and confident ride on the roughest of terrain. And with the power of Creo 2 Alloy, you can take all that tire volume to the road with no penalty for a next-level silky ride.
– FUTURE SHOCK 2.0: The Creo 2 Alloy features Future Shock 2.0, with 20mm of smooth travel at the handlebars, that reduces impacts by 53%. Future Shock helps keep your hands and bars steady for a smoother ride with more control to stay fast, safe, and confident—all while helping reduce fatigue over long days in the saddle.
– THE GEOMETRY OF CAPABILITY: The Creo 2 Alloy boasts our most progressive geometry yet that will have you ripping everything from wide open roads to dicey gravel tracks with ultimate confidence. A more ergonomic endurance position feels great, with the power to ride all day.
– LOAD UP, HEAD OUT: Take a little or a lot on any ride. Creo 2 Alloy accepts a variety of front, rear, and low-rider racks. Who says you can’t take it all?
– YOU’RE IN CONTROL: Our most advanced and intuitive e-bike control unit. Connecting the bike, the Turbo OS, the Specialized App, and the rider, all in a protected and easily visible display. With MicroTune, fine-tuning power output levels in real time is at your fingertips, optimizing your range management and performance.
– MASTERMIND TCU: The MasterMind TCU is the brain of the bike. Displaying all relevant info about your ride, it allows real time tuning of support levels, enables over-the-air updates so that your bike gets better over time, and seamlessly integrates with the Specialized app for advanced tuning, on-trail diagnostics, customizable display, and more.
– ALL-NEW SPECIALIZED APP: The Creo 2 Alloy integrates fully with our Specialized App and lets you personalize your motor characteristics. You can record your rides, personalize your screens, track your data, sync with other apps, and even thwart would-be thieves with Turbo System Lock.
Geometry
Frame Size
49cm
52cm
54cm
56cm
58cm
61cm
Crank Length (mm)
165
170
172.5
172.5
175
175
Handlebar Width (mm)
380
400
420
420
440
440
Stem Length (mm)
60
70
80
90
100
100
Saddle Width (mm)
155
155
143
143
143
143
Seatpost Length (mm)
350
350
400
400
400
400
Stack (mm)
578
578
595
607
638
663
Reach (mm)
365
374
383
392
401
410
Head Tube Length (mm)
90
90
108
120
153
180
Head Tube Angle (°)
71
71
71
71
71
71
Bottom Bracket Height (mm)
270
270
270
270
270
270
Bottom Bracket Drop (mm)
80
80
80
80
80
80
Trail (mm)
62
62
62
62
62
62
Fork Length, Full (mm)
405
405
405
405
405
405
Fork Rake/Offset (mm)
55
55
55
55
55
55
Front Center (mm)
600.1
609
623.8
636.6
656.2
673.8
Chainstay Length (mm)
435
435
435
435
435
435
Wheelbase (mm)
1022
1031
1046
1059
1079
1097
Top Tube Length, Horizontal (mm)
531
540
554
572
590
613
Standover Height (mm)
731
743
773
793
824
852
Seat Tube Length (mm)
410
430
470
500
530
560
Seat Tube Angle (°)
74
74
74
73.5
73.5
73
Sizing
Frame Size
Rider Height (in.)
Rider Height (cm)
49cm
5’0″–5’4″
152–163
52cm
5’4″–5’7″
163–170
54cm
5’7″–5’10”
170–178
56cm
5’9″–6’0″
175–183
58cm
5’11″–6’2″
180–188
61cm
6’2″–6’9″
188–205
* Sizing is intended as a guide. If you are between sizes, consider your riding style and preference.
Specs
Motor
Specialized 1.2 SL Custom Lightweight Motor
Battery
Specialized SL1-320, fully integrated, 320Wh
Controller/Display
Specialized MasterMind TCU, percentage of remaining charge, 120 possible display configurations, MicroTune assist adjustment, over-the-air updates, ANT+/Bluetooth®, w/Handlebar remote
Charger
Custom charger, 48V System w/ SL system charger plug
